| Maxisys MS906 | Maxisys MS906BT | Maxisys MS906TS | |
| Operating System | Android 4.4.2, KitKat | Android 4.4.2, KitKat | Android 4.4.2, KitKat |
| Processor | Samsung Exynos 6-Core Processor (1.3GHz quad-core ARM Cortex-A7+1.7 Ghz dual-core ARM Cortex-A15) | Samsung Exynos T5260 6-Core Processor (1.3GHz quad-core ARM Cortex-A7+1.7 Ghz dual-core ARM Cortex-A15) | Samsung Exynos T5260 6-Core Processor (1.3GHz quad-core ARM Cortex-A7+1.7 Ghz dual-core ARM Cortex-A15) |
| Memory | 2GB RAM & 32GB ROM | 2GB RAM & 32GB ROM | 2GB RAM & 32GB ROM |
| Display | 8.0" LED capacitive touch screen with 1024×768P resolution | 8.0" LED capacitive touch screen with 1024×768P resolution | 8.0" LED capacitive touch screen with 1024×768P resolution |
| Connectivity | Wifi (802.11 b/g/n) DB16 DLC USB 2.0 |
Wifi (802.11 b/g/n) BT (Bluetooth) HDMI Port USB 2.0 |
Wifi (802.11 b/g/n) BT (Bluetooth) HDMI Port USB 2.0 |
| Camera | Rear 8.0 Megapixel, AF with Flashlight | Rear 8.0 Megapixel, Autofocus with flashlight | Rear 8.0 Megapixel, AF with Flashlight |
| Power & Battery | 10000 mAh 3.7V lithium-polymer battery | 10000 mAh 3.7V lithium-polymer battery | 10000 mAh 3.7V lithium-polymer battery |
| Full Set of OBD1 Adapter | YES | YES | YES |
| Wireless VCI | YES | YES | YES |
Autel MS906 VS MS906BT VS MS906TS on Software
| Maxisys MS906 | Maxisys MS906BT | Maxisys MS906TS | |
| Diagnostic Service | Advanced full system diagnostics (for 80+ US, Asian and EU makes and models) Read codes, Erase Codes, Live data, ECU information, I/M readiness, Complete OBD diagnostics |
Advanced full system diagnostics (for 80+ US, Asian and EU makes and models) Read codes, Erase Codes, Live data, ECU information, I/M readiness, Complete OBD diagnostics |
Advanced full system diagnostics (for 80+ US, Asian and EU makes and models) Read codes, Erase Codes, Live data, ECU information, I/M readiness, Complete OBD diagnostics |
| 20+ Special Service | Oil Reset, EPB, TPMS, BMS, Auto Bleeding, DPF, Airbag Reset, Injector, SAS, Suspension, Throttle, Win DR Roof, Seat, Lang Change, Headlamp, CHG Tire size, TEC learn, Cylinder, Turbocharging, Transadaption | Oil Reset, EPB, TPMS, BMS, Auto Bleeding, DPF, Airbag Reset, Injector, SAS, Suspension, Throttle, Win DR Roof, Seat, Lang Change, Headlamp, CHG Tire size, TEC learn, Cylinder, Turbocharging, Transadaption | Oil Reset, EPB, TPMS, BMS, Auto Bleeding, DPF, Airbag Reset, Injector, SAS, Suspension, Throttle, Win DR Roof, Seat, Lang Change, Headlamp, CHG Tire size, TEC learn, Cylinder, Turbocharging, Transadaption |
| ECU Programming | No | No | No |
| ECU Coding | No | Yes | Yes |
| Complete TPMS | Basic TPMS | Basic TPMS | Complete Advanced TPMS |
| Auto VIN Technology | Yes | Yes | Yes |
| Add on Oscilloscope | No | Yes | Yes |
| Add on Inspection Camera | No | Yes | Yes |
| ADAS | Yes | Yes | No |
Similarities and Differences Between The Autel MS906 VS MS906BT VS MS906TS
1. Similarities Among Autel MS906 VS MS906BT VS MS906TS
Among the three scanners, the MS906 diagnostic scanner is the most basic, followed by the MS906BT and the most advanced scanner is the MS906TS. These scanners share a lot of features such as Samsung Exynos Hexa-core processor, Android 4.4.2 KitKat, 32 GB memory, 8 MP camera, AutoVin technology, and have MaxiFix Cloud-based information system.
2. Difference Among Autel MS906 VS MS906BT VS MS906TS Scanners
Besides having the same features, these scan tools also vary in many ways. First of all, the MS906BT and MS906TS feature Bluetooth connectivity while the MS906 doesn't have one. Additionally, they have wireless VCI while MS906 doesn't have one. Furthermore, the MS906TS provides comprehensive TPMS solution, while the MS906 and MS906BT just have basic tpms like tpms sensor id relearn but don't programming sensor, which is the main difference between the Autel MS906BT and MS906TS.
Price wise, the MS906 is the cheapest amongst the three, followed by MS906BT and finally the MS906TS. Of course, you can choose MS906BT + TS501 to instead MS906TS, because this bundle has total same functions as MS906ts but cheaper. Make a wise choice and select a diagnostic scanner that meets your needs and demands.
3. MS906, MS906BT and MS906TS, Which One is Best for You
The Autel MS906 scan tool series is one of the best as it features different high-quality scanners that are built for professional use. But you have to choose one right. Different technicians and mechanics have different needs. So, depending on what you want the code reader to diagnose, you may find one of these tools to be the most ideal for your job.
If you want a professional scanner at a great price, then you should go for the MS906BT scan tool. But if you want a more advanced scanner with complete TPMS service, then the Autel MS906TS is the device for you or choose MS906BT +TS501.
| Functions | Maxisys MS906 | Maxisys MS906BT | Maxisys MS906TS |
| All Systems DTC Scan | √ | √ | √ |
| Service Function | √ | √ | √ |
| Bi-Directional Control | √ | √ | √ |
| Auto VIN Technology | √ | √ | √ |
| ECU Coding | -- | √ | √ |
| ECU Programming | -- | -- | -- |
| MaxiFix Cloud-Based Info System | √ | √ | √ |
| Data Manager | √ | √ | √ |
| Shop Manager | √ | √ | √ |
| Remote Support | √ | √ | √ |
| Pre-scan Report & Post-scan Report | North America Only | North America Only | √ |
| Print Feature | √ | √ | √ |
| Multi-language Support | √ | √ | √ |
| Coverage | |||
| Domestic/Asian/European Coverage(1996-Present) | √ | √ | √ |
| Hardware | |||
| Display Size | 8" | 8" | 8" |
| Wireless VCI | -- | MaxiVCI V100 | MaxiVCI V100 |
| Battery Life | 5000 mAh 3.7 V | 10000 mAh 3.7 V | 10000 mAh 3.7 V |
| Memory Storage | 32GB | 32GB | 32GB |
| Connector Kit | √ | √ | √ |
| Options | |||
| TPMS | -- | -- | √ |
| Oscilloscope | -- | √ | √ |
| Inspection Camera | -- | √ | √ |
| ADAS | √ | √ | -- |
